***SPECIFICATIONS***

Voltage rating: 250V AC, DC

Current rating: 3A, AC, DC

Withstanding Voltage: 1500V AC/minute

Insulation resistance: 500MΩ min

Temperature range: -25°C~+85°C

Contact resistance: 20mΩ max

HOUSING

Part No.: H2513-02P/H2514-02P

Housing Material: Nylon66 UL94V-2

TERMINAL

Part No.: T2513BT/T2514BT

Applicable wire: AWG#22-#28

Material: Brass

Finish: Tin Plated
